    Hi,

    thank you for accepting my membership. Here is my first grow here (5th in my life).

    I grow in my diy box, insulated, inside coated by Orca foil, outtake fan, air circulation fan. Inner diameters: 70*70*220 cm (cca 2.3*2.3*7.3fee)

    My diy lights are
    1) 1 chip Vero 29, C version 5000k 70cri
    2) 3 chip Vero 29, C version 3000k 90cri

    I use first one for grow, lot of blue light helps hold my flower short and wide and second one for flower

    Light intensity is measured by my Iphone app called Photone - in tests measures +- 5% like Apogee - good enough for me

    Nutrients - complete Canna aqua line, I use bluelab device to measure pH and EC. My tapwater is 0.6ec so i use distíled wateror rain water to dilute it to 0.4. In later stages of growth I will try torus hydro perfect pH capsule. In flower I use cc 80l(21gal) dwc tank - i can leave it without attention later. In groe i use cca 20l tank(5gal).

    I made diy arduino controlling machine, now it senses - air temp and humidity, co2, water temp, and controls outtake fan and light - still in developement i want to add co2 enrichment, but i need much larger grow chamber, with at least dehumidifier or bether AC. I also want to collect data and sendit to thingspeak to have online monitoring in future.


    Attachments

    • A237495E-891F-4440-9957-A24042F20FDD.jpeg
      2.7 MB · Views: 59
    • 9E3192CF-10A1-413E-A4A0-0BFA894D3A86.jpeg
      1.1 MB · Views: 57
    • A2433E17-DA23-466E-BAF2-97EA8A61FB3D.jpeg
      1.2 MB · Views: 58
    • 879B0A95-D1DB-4169-B9D2-64E297F8F03F.jpeg
      1.3 MB · Views: 59
    • 1A6AA311-A51C-48DC-9786-9990F876C6D8.jpeg
      753 KB · Views: 57
    • 76B23F27-D4BF-4ACE-9F28-1D13C284C8E0.jpeg
      1.4 MB · Views: 56
    • 77FF6D6C-38A2-4AD2-AE58-F21E9E86D9FC.jpeg
      546.8 KB · Views: 60
    • 252AF191-4AC7-4B39-8780-8BAB9AC40632.jpeg
      2 MB · Views: 63
    • B527400E-C086-457C-9D64-98C0B8A4D446.jpeg
      2.4 MB · Views: 55
    Last edited:
    Day 2
  • Day 2 after sprouting.

    I put it in small dwc tank, only little bit of grownuts and lot of rhizotonic, ec 0,6. My grow ligth ppfd is 300, 18hours light and 6hours dark

    One more idea to say: i will be happy if you write me some ideas how to improve my settup or grow. I also love to read If you thing that Iam doing something wrong way.


    Attachments

    • 1E94FAA1-3611-44AB-A8F8-998A05363474.jpeg
      1.8 MB · Views: 35
    Day 10
  • Update day 10.

    Firstroots came out of of hydroponic basket, so I put it in 20l (5gal)reservoir.

    EC 0.9 my aim was 0.8 but shaking hand :-). I mixed my tapwater (ec 0.6) with rainwater (ec 0.1) to ec 0.4 due to recommendation of Canna.

    Ph corrected to 5.8 - and now it should be cared by torrus hydro perfect pH capsule

    Light - ppfd about 625. Blue one 5000k 70cri. I thing this shoud hold my flower down ,bushy with masive root mass and thick stem.

    I also added some hydroton to suppoort

    Best light to everyone!

    Last edited:
    Day 14
  • Day 14 update

    PPFD 900

    everything goes well so far, growth is starting to accelerate. There is nothing to do.

    Environment is controlled by arduino, in the reservoir there is enough nutrients for weeks, ph is being held by perfect ph.

    In few day I will only check EC.

    Water temp is same like last time, higher than it should be, but it doesnt do anything, so I will not do anything - I am lazy man. Maybe hydroguard or something simillar could make me feelig more comfortable, what do you think?

    Good luck guys


    Last edited:
    Day 21
  • Day 21

    Hi, so far so good.

    I added 1,5l(0.4gal) of distilled water to hold EC 1.0 and adjusted lights few times to hold ppfd in center part between 900-1000umol/m2/s.

    Ph is stable between 5,7-6.2, checkef few times, yesterday it was 6.1




    Attachments

    • 23A153DA-3928-43F3-BA34-8C94316C1AA9.jpeg
      1.4 MB · Views: 16
    • 0D19A21F-C8E7-43F4-BA9A-DAFC262B82E0.jpeg
      970.6 KB · Views: 21
    • F3EFC90E-1DB1-45D9-821D-64DCFF50F2E1.jpeg
      1.7 MB · Views: 22
    • 8EE8D1B0-79D3-4582-A221-16C574BDB773.jpeg
      3.9 MB · Views: 22
    Day 28 update
  • Hi,

    day 28 update. Ph was going up to 6.5, so i recharhed my pH perfect capsule. It was in use only 6 weeks. It
    was in 80l reserwoir although it is aimed to 380l.

    Tomorrow I will switch to final container (80l - 21gal) and hope there will be no more pH issues. It will be 80l (21gal) of grow sollution, i think last grow sollution for this plant.

    Plant grew nice, nearly full space is filled, still under 60w blue light!!! It also showed first white pistils. Also tipburs are aparrent. Hope there will be no more.
