Indoor The Elvis Builds a Lamp!!

[The Elvis]

Hello ladies and gentleman I am building a DIY Bridgelux gen 7 vR 29 COBs X 4
I am currently building my own frame, and its just about done..

Bridgerlux VR29 X4
SST X passive heat sinks X4
LEDiL reflector kit 4 cups
HLG-120H-C1400b X4 mean well



lets start the build!!!

SAFETY FIRST!!!

i will be using a 3X3 L bracket aluminum frame. this frame is 100% up gradable and I do have plans to add 2 more SSTX sinks on the lamp frame.

I chose to use rivets to keep it together im trying to keep this lamp under 20lbs..

Here im checking all my measurements to make sure this is the direction i want to go!!
I like it!!

just Mocking it up for future plans!!!

this is the basic lay out of the lamp. i will make more "some" changes as time goes on!!!

i will also paint it British racing green!!!

Big shout out to @PhotonLabs

This frame was a project for sure.. not that hard to dream up or even build..

I do believe i should slot those rails so those Sinks could slide in and out @pop22
track lighting!!! I will also be using two photometers to control each side and yes ill solder in the diodes..

Bridgelux Vr29s!



[Habitual]

Been waiting on this one... Gotta love some rivets, change = drill bit


You got Snoop up off the couch lol



[AJrexxx]

Very interesting I am kind of looking at doing something similar for my first project of the new year.



[Starbreaker]

Hello ladies and gentleman I am building a DIY Bridgelux gen 7 vR 29 COBs X 4
I am currently building my own frame, and its just about done..

Bridgerlux VR29 X4
SST X passive heat sinks X4
LEDiL reflector kit 4 cups
HLG-120H-C1400b X4 mean well



lets start the build!!!

SAFETY FIRST!!!

i will be using a 3X3 L bracket albumin frame. this frame is 100% up gradable and I do have plans to add 2 more SSTX sinks on the lamp frame.

View attachment 674292

I chose to use rivets to keep it together im trying to keep this lamp under 20lbs..

Here im checking all my measurements to make sure this is the direction i want to go!!
I like it!!

View attachment 674294

just Mocking it up for future plans!!!

View attachment 674296
this is the basic lay out of the lamp. i will make more "some" changes as time goes on!!!

i will also paint it British racing green!!!

View attachment 674297

View attachment 674299


Big shout out to @PhotonLabs

This frame was a project for sure.. not that hard to dream up or even build..

I do believe i should slot those rails so those Sinks could slide in and out @pop22
track lighting!!! I will also be using two photometers to control each side and yes ill solder in the diodes..

Bridgelux Vr29s!
View attachment 674452

Gonna be sweeeeeeet!



[The Elvis]

thank you star!!

The frame is done and i am happy!! Its been primed and is now siting and drying.. wow this is fun!!! @arty zan The British racing green looks tits!!!!
lets have a look!!! i have pre drilled all my holes and so I should be good to go to starting my electrical part of my build.. i will be soldering with heat shrink tube most of the wires but the 100V ill use caps because ill open that box up soon and add another driver... hell everything in my home has twist connectors.. US..

primed!!!

First coat of British racing green!!! @bigsmo

3rd coat and almost dry!!



[The Elvis]

Paint is all dry and looks great!! @pop22 we gotta racer!!

man I have so much wiring to do!!! I'm so close!!! here are some pics!!!

the lekki work starts tomorrow!!!!

just thinking it all out!!!



[pop22]

WOOOOOOOOOooooooooooooo! I wantr to see it lit up! Got yourself a badass peice of equipment my friend!



[AJrexxx]

The green looks sweet.

Sent from my 2PQ93 using Tapatalk



[The Elvis]

Thank you very much!! passes to @bf80255



[Dr Fluff]

Looking fantastic @The Elvis , yeah the racing green looks really nice!
The heat sinks look amazing but so do you COB chips!!
I'm really looking forward to the electrics being done and finished!
